Eppendorf Mastercycler Pro
- Description
- Specifications
- Included
- Notes
- Video
Description
Description
Eppendorf Mastercycler Pro
The Eppendorf Mastercycler Pro Thermal Cycler offers a flexible powerhouse with consistent heating and cooling. This PCR can operate in three modes, stand-alone, min-satellite, or as a daisy-chained PC-controlled network. This PCR machine features Steadyslope and Vapo protect technology, to keep temperature rates consistent and reduce evaporation, allowing users to work with low reaction volumes. Heating and cooling in this thermal cycler happen rapidly thanks to a hot start function that increases rates up to 6° per second (Pro S Model only).
The Eppendorf Mastercycler Pro PCR allows you to be modular with your block formats, with an intuitive graphic display to guide users through programming. Programming the gradient functions through the control panel is designed to get even the most inexperienced user up and running safely. Gradient temperatures in this PCR Cycler can be programmed freely across 12 rows, with a range of up to 20°C (Pro Model) or 24°C (Pro S Model) thanks to the aluminum (Pro) or silver block (Pro S). The gradient slope of these Eppendorf PCR systems makes sure identical heating and cooling ramp rates are present in both standard and gradient functions. At the same time, the heated lid uses integrated thermal sample protection to keep samples safe.
Specifications
Specifications
Eppendorf Mastercycler Pro PCR Specifications:
Thermoblock | Aluminum |
Temperature control range of the block | 4 – 99 °C |
Temperature Uniformity | ≤±0.4°C at 95°C |
Temperature control mode | Fast, Standard, Safe |
Heating technology | Peltier elements, Triple Circuit Technology |
Sample capacity | 96 x 0.2mL PCR tubes or 1 PCR plate 8 x 12 (unskirted, semi skirted, skirted,SBS standard) |
Gradient range | 1 – 20 °C |
Gradient temperature range | 30 – 99 °C |
Lid temperature range | 37 – 110 °C |
Block homogeneity | @20–72 °C ±0.3 °C |
Block homogeneity | @90 °C ±0.4 °C |
Block temperature accuracy | ±0.2 °C |
Heating rate | 6 °C/s 1 |
Cooling rate | 4.5 °C/s 1 |
Interfaces | 1 × Centronics, 1 × RS-232, USB at Control Panel, one each of CAN_in/CAN_out |
Total weight | 38 lbs |
Power supply | 115/130V, 50/60Hz |
Max. power consumption | 950 W |
Dimensions | 10x22x15 “ |
Included
Included
Included with Eppendorf mastercycler
Eppendorf MasterCycler Pro | CAT# 6321
96 Well Block
LCD Controller
User Manual
120V Power Cord (8A)
30-Day Warranty
Notes
Notes
Technical Notes on Eppendorf thermal cycler
Eppendorf thermocycler has been thoroughly inspected and is operating without issue. All of our lab equipment comes backed by our standard warranty. Should you have any questions, please don’t hesitate to contact us.
Video
Video
Eppendorf PCR Machine Video
Eppendorf MasterCycler Video ID 19602
