Hamilton Syringe Pump

The Hamilton MICROLAB 600 Syringe Pump provides a versatile, repeatable method of dispensing and diluting for any manual pipetting application. This lab syringe pump features an intuitive touch screen control, with icon-based navigation. From this control panel, users can select their syringe volume between 10 µL–50 mL across two syringes, allowing users to create up to a 1:50,000 dilution in one step. This helps reduce preparation time and conserves buffer solution. This Hamilton pump features a step-driven motor with high precision and a speed that ranges from 0.003-6,000 µL/sec. The range of the speed will be determined by the size of the syringe size being used.

The tubing is washed between each sample, minimizing carryover and making it ideal for applications such as atomic absorption, HPLC, GC, and ICP.  Samples and diluent volume are programmed into the instrument, then the operator triggers aspiration and dispensing from the hand probe. Users can choose dual syringe dilution, serial dilution either programmed or tube to tube, and multi-sample dilution. The lab syringe pump has an operating temperature range of between 5-40°C and an rH range between 20-90% noncondensing.

Specifications

Hamilton MICROLAB 600 Syringe Pump Specifications:

Fluid path FEP, CTFE, PTFE, Borosilicate Glass
Syringe size 10 µL–50 mL
Number of Syringe Drives Two
Syringe Drive Mechanism Stepper motor driven high precision lead screw with encoder
Sample Volume Range 1.0 µL–50 mL
Speed (µL/sec, syringe size dictates range) 0.003-6,000
Recommended Operating Temperature Range 41–104°F (5–40°C)
Humidity Range 20–90% non-condensing
Program memory One program stored in memory while power is on
Dimensions 9 x 6 x 14”
Weight 13 lbs
Power 100–240 V 1.5A max 50/60 Hz

Included

Included with this lab syringe pump

Hamilton Syringe Pump Microlab 600 Series | CAT# 61502 | MSRP: $5700.00
User Manual
120V Power Cord
30-Day Warranty

Notes

Technical Notes

This Hamilton syringe pump has been fully inspected and is ready to ship. All of our lab equipment comes backed by our standard warranty. Should you have any questions, please don’t hesitate to contact us.

Video

Hamilton Syringe Pump Video
