Leica CM1510 Cryostat

0 out of 5
( There are no reviews yet. )

$6,499

Availability: 1 in stock SKU: 24518 Categories: ,
View cart View Quote List

Description

Leica CM1510 Cryostat

The Leica CM1510 is an open-top cryostat with rapid built-in specimen freezing and manual sectioning. It is ergonomically designed for seated use, featuring a knee well and a lockable, counterbalanced handwheel positioned for smooth operation during manual sectioning. The section thickness range is 1 to 50 µm, with a specimen feed of 25mm and a vertical stroke of 59 mm.

The corrosion-proof cryochamber of this Cryostat can be set between 0 °C and -30°C and features a quick-freeze shelf with up to 10 spaces for specimens, capable of reaching a maximum temperature of -44°C. The Stainless-steel rotary microtome has an 8° X/Y/Z specimen orientation and is virtually maintenance-free. To keep the Cryostat frost-free, users can implement an 8-minute defrost cycle, either manually or set up a scheduled program for maintenance.

Specifications

Leica CM15103 Cryostat Specifications

Section thickness range  1 – 50 µm

in 1 µm increments from 1 to 10 µm
in 2 µm increments from 10 to 20 µm
in 5 µm increments from 20 to 50 µm
Horizontal Specimen feed 25 mm
Vertical cutting stroke  59 mm
Maximum Specimen Size 40mm x 55mm
Trimming 5 to 150 μm ± 0,5 μm in steps of 5, 10, 30, 50, 100 and 150 μm
Specimen precision orientation by 8° (x/y/z axis)
Cutting speed: 0.1 mm/s to 170 mm/s
0.1 mm/s to 100 mm/s
Vmax: 210 mm/s
Cryochamber Temperature Range 0 °C to -30 °C ±10%
at an ambient temperature of 22 °C
and air humidity <_ 60%
when sliding window is closed;
adjustable in 1-degree increments
Freezing shelf temperature Approx. -44°C at an ambient temperature of 22°C
Defrost at a chamber temperature between -20 °C and -30 °C

automatic hot gas defrosting,
defrost time freely programmable,
manual defrosting
duration: 8 min.
Dimensions (L x W x H) 28x27x47”
Weight 264 lbs
Power supply 120 V, 60 Hz, 1500va

Included

Included with this Cryostat

Thermo Shandon Cryostat CM 1510-3 | Cat#043631517
Blade Holder Assembly
User Manual
120V Power Cord (12A)
30-Day Warranty
Please Note: The orange datalogger seen in photos is not included. This is our testing tool to demonstrate a fully working system.

Notes

Technical Notes

This Leica Cryostat has been thoroughly inspected and is operating without issue. All of our lab equipment comes backed by our standard warranty. Should you have any questions, please don’t hesitate to contact us.

Video

Leica CM15103 Cryostat Video

Leica CM15103 Cryostat ID 24518
