Leica RM2165 Microtome
The Leica Rotary Microtome RM2165 provides reliable, automated sectioning, with the flexibility of operating either motorized or driven by hand. This rotary microtome can be set into coarse or fine ranges, from 0,25 µm, 0,5 µm, 1 µm, 1,5 µm, and in increments of 1 µm from 2 -20 µm and increments of 5 µm from 20-60 µm with a vertical stroke of 70µm. The sectioning uses a motorized stepper that will advance 28 µm ±1 µm, and can be done either in a single or continuous stroke, or when operating manually with the handwheel in a rocking mode.
The rocking mode of this rotary microtome is particularly efficient and fast for small specimens. This microtome is operated from the control panel with a digital display, including section and trimming thickness, sectioning speed, coarse and fine specimen advance, sectioning window size, and sectioning mode. The Leica RM2165 can also be controlled with the foot pedal, freeing up hands for added flexibility.
Specifications
Specifications
Leica RM2165 Microtome Specifications:
| Cut thickness range | 0.25- 60 um
0,25 µm, 0,5 µm, 1 µm, 1,5 µm increments of 1 µm from 2 -20 µm increments of 5 µm from 20-60 µm |
| Advance of the object | 28 µm ±1 µm
advance by stepper motor |
| Vertical stroke | 70 µm |
| Max. Cutting range without retraction | 65 µm without sample orientation |
| Max. Cutting range with retraction | 60 µm |
| Retraction of the object | in manual cutting 5-100 µm with 5 µm
increments can be turned off in motorized cutter speed function can be turned off |
| Motorized approach | 300 µm/s et 900 µm/s |
| Cutting Speed | 0; 0,5 – 420 µm/s |
| Moving the knife holder base | north south ± 25 µm
east west ± 20 µm |
| Orientation | 8° Horizontal
90° Rotation |
| Dimensions | 21x15x12” |
| Weight | 96lbs |
| Power | 100/120/230/240 v, 50/60 hz, 340 va |
Included
Included
Included with Leica RM2165 Microtome
- Leica RM2165 Microtome
- Joystick Controller
- Foot Pedal
- Locking Head for Blade
- 115V Power Cord
- Operator’s Guide
- 30-Day Warranty
Notes
Notes
Technical Notes
This Leica RM2165 Microtome has been fully inspected and is operating without issue. All of our lab equipment comes backed with our standard warranty. Should you have any questions, please don’t hesitate to contact us.
Video
Video
Leica RM2165 Microtome Video
Leica Rotary Microtome RM2165
