Quincy Scroll Air Compressor
- Description
- Specifications
- Included
- Notes
- Video
Description
Description
Quincy Scroll Air Compressor
The Quincy Scroll Air Compressor is an oil-free class zero scroll compressor with high sustainability and minimal maintenance. Oil-free compressors offer your lab high-efficiency operation, the highest level of air purity, and reduced risk of contamination while being a lower cost to operate. The QOF-15 Quincy produces oil-free air certified ISO 8573-1 compliant and is ideal for pharmaceutical, lab, food, and textile work.
The Quincy Scroll Air Compressor is set in a cool-canopy enclosure that increases ventilation while lowering heat output. Settings are controlled through the command center, which regulates system pressure up to 116PSI, with 43CFM and a noise level of 63 dBA. Partnered with this scroll air compressor is a Nano NDL 060 Low Dew Point Desiccant air dryer for added protection against moisture and particulates when using the compressor system at the point of application. This compressor system can also be used with the Deltech HG50 Air Dryer, copper tube-on-tube heat exchangers that provide low-pressure dew point performance, and a centrifugal separator that efficiently collects liquid condensate. This Quincy air compressor for sale provides multiple options and levels of control for your compressed air needs. Contact us with any questions.
Specifications
Specifications
Quincy Scroll Air Compressor System Specifications:
QOF-15 | |
Engine | 15HP |
Pump | 43CFM |
Max PSI | 116 PSI |
Pump Type | Scroll Compressor |
Pump Drive | Belt Drive |
Oil Type | Oil Free |
Tank Outlet | 1/2 Inch |
Noise Level | 63 dBA |
Dimensions | 70x30x49” |
Weight | 1700lbs aprox |
Power | 230 V AC, 3-Phase |
Nano NDL 060 | |
Capacity | 34 SCFM |
Maximum Working Pressure | 232 PSIG |
Inlet/Outlet Connection | 1″ NPT |
Pressure Rating | 232° |
Power | 100 to 240 VAC / 50 or 60Hz power supply |
Deltech HG50 Air Dryer | |
Air Flow Rate | 50 scfm |
Air Pressure | 100 psig |
Dew Point Temperature | 38 deg F |
Drain Type | Timer |
Inlet Air Temperature | 100 deg F |
Inlet Connection Size | 3/4 in |
Maximum Temperature | 100 deg F |
Outlet Connection Size | 3/4 in |
Refrigerant Type | R-134A |
Power | 115V |
Included
Included
Included with this Oil Free Compressor System
Quincy Air Compressor | Scroll Air Compressor | CAT# Q0F-15 | MSRP: $32,336.00 (Total System Value: $45,259.00)
Nano NDL 060 Low Dew Point Desiccant Air Dryer | MSRP: $7,077.00
Deltech HG50 Air Dryer | MSRP: $3216.00
120 Gallon Air Tanks (2qty) | MSRP: $2630.12
30-Day Warranty
Please Note: Compressor should be professionally installed and requires some plumbing as copper piping is not included.
Notes
Notes
Technical Notes
This Quincy Compressor has been fully inspected and is ready to ship. All of our lab equipment comes backed by our standard warranty. Should you have any questions, please don’t hesitate to contact us.
Video
Video
Quincy Compressor Video
Quincy Scroll Air Compressor ID 18885
