Specac Atlas Hydraulic Press 25T
The Specac Atlas Hydraulic Press 25T brings users an easy-to-operate manual press for sample preparation. This pellet press and interchangeable pellet die is built to cover multiple press uses, particularly prepping solid samples for XRF analysis. This Specac hydraulic press machine is rated at 25 tons and has a lower piston stroke of 25.4 mm. The rugged hardware design and polycarbonate safety guards ensure safe operation. The upper bolster and pressure relief valves are adjustable so users can make corrections as they go. This press comes with a variety of dies that can be swapped depending on the task with more available from the Manufacturer including those used for KBr disks or heated platens when working with polymer films. Users can also find a low-pressure gauge option through the manufacturer for a wider range of uses.
Specifications
Specifications
Specac Atlas Hydraulic Press 25T Specifications:
| Lower piston stroke | 25.4 mm |
| Upper bolster screw trave | 89 mm |
| Distance between pressing faces (max) | 152 mm |
| Distance between pressing faces (min) | 38 mm |
| Lower pressing face diameter | 86 mm |
| Upper pressing face diameter | 32 mm |
| Max width of sampling area (side to side) | 143 mm |
| Max depth of sampling area (front to back) | 141 mm |
| Dimensions | 12x8x24” |
| Weight | 109 lbs |
Included
Included
Included with this manual hydraulic press
Specac Atlas Hydraulic Press 25T | Manual | 25 Ton Capacity | MSRP: $5800.00
Change Parts
Hydraulic Oil
30-Day Warranty
Notes
Notes
Technical Notes
This hydraulic pellet press has been fully inspected and is operating without issue. All of our lab equipment comes backed by our standard warranty. Should you have any questions, please don’t hesitate to contact us.
Video
Video
Specac Atlas Hydraulic Press 25T Video
Specac Atlas Hydraulic Press 25T ID 17810
