BioTek PowerWave HT UV-Vis Microplate Reader

$0

Availability: Out of stock SKU: UNK452 Category:

Description

Biotek Powerwave HT Microplate Spectrophotometer

The BioTek PowerWave HT UV-Vis Microplate Reader offers users a top-notch monochromator-based platform in a compact design that takes up minimal bench space. This 8 Channel Absorbance Microplate uses a filter wheel allowing users to select the needed wavelength without the tedium of changing out filters. Users of this UV-Vis Microplate reader can perform endpoint and kinetic analysis, with the maximum absorbance from any sample.



The BioTek PowerWave HT UV-Vis Microplate Reader provides reliable and accurate data with wavelength measurements in 200 nm to 999 nm in 1 nm increments, with an accuracy of +/- 2 nm and readability of +/- 0.2 nm.  This Microplate reader has three reading speeds, can be used as either a standalone assay system or as part of a larger lab network. The PowerWave HT is compatible with the BioTek BioStack Robot making it automated-capable. Using Gen5 software for data acquisition, this robust BioTek PowerWave HT UV-Vis Microplate Reader works with a wide range of assays including ELISA, colorimetric assay, multiwavelengths, spectral scanning, enzyme kinetics, RNA quantitation, DNA quantitation, purity testing, and much more.



The BioTek PowerWave HT UV-Vis Microplate Reader uses a xenon flash lamp for both UV and visible light UV-Vis methods and handles both 96 and 384 well microplates with an extended dynamic range of up to 4.000 OD. It also comes equipped with variable microplate shaking technology, and 4 zone temperature control incubation of 4° over ambient to 50°C.  This UV-Vis plate reader comes with communication and power cables, as well as a Gen5 computer workstation.  The PowerWave HT from Biotek can read 96-well microplates within five seconds making this plate reader a top choice among scientists.

Specifications

Biotek Powerwave HT Microplate Spectrophotometer Specifications:

 General



Detection modes



UV-Vis



Read methods



Endpoint, kinetic, spectral scanning



Microplate types



96- and 384-well plates



Temperature control



4-Zone incubation to 50 °C  +/- 0.2 °C at 37 °C

Shaking



Linear



Software



Gen5 Data Analysis Software



Absorbance



Light source



Xenon flash



Detector



photodiode



Wavelength selection



monochromator



Wavelength range



200 to 999 nm, in 1 nm increments



Monochromator bandwidth



5 nm



Dynamic range



0 – 4.0 OD



Resolution



0.001 OD



Pathlength correction



yes



Monochromator wavelength accuracy



+2 nm



Monochromator wavelength repeatability



+0.2 nm



OD accuracy



1% + 0.01 OD



OD linearity



+1%



Reading speed (kinetic)



96 wells: 5 seconds, 384 wells: 11 seconds



Physical Characteristics



Power



 100-240 Volts AC. 50/60 Hz.



Dimensions



8.5″W x 16″D x 8.5″H  (21.6 x 40.6 x 21.6 cm)



Weight



24 lbs (11 kg)



Environment:



Operational temperature 18°-40°C



Humidity:



10% to 80%, non-condensing



Incubation option: Temperature Control:



4°C over ambient to 50°C



Temperature Variation:



± 0.5°C across the plate @ 37°C



Communication



One serial COM port (25-pin male connector)



Included

Included with Biotek Powerwave HT Microplate Spectrophotometer

  • BioTek PowerWave HT UV-Vis Microplate Reader
  • Windows 7 Computer with Software
  • Instrument Validation Report
  • Absorbance Validation Report
  • Operator’s Guide
  • Power Cables
  • Communication Cables
  • 30-Day Warranty

Notes

Technical Notes

This BioTek PowerWave HT UV-Vis Microplate Reader has been thoroughly inspected and is performing to expectations. All of our lab equipment comes backed with our standard warranty. Should you have any questions, please don’t hesitate to contact us.

Video

Biotek Powerwave HT Microplate Spectrophotometer Video

BioTek PowerWave HT UV-Vis Microplate Reader
