KrosFlo TFF System

Availability: Out of stock SKU: 15428 Category:

Description

KrosFlo TFF System

The KrosFlo Research II Tangential Flow Filtration System provides fast, gentle microfiltration and ultrafiltration with maximized product recovery for small applications.  This TFF system has a flow rate range from 0.01 to 2300 ml per minute and uses a disposable flow path and digital pressure monitor to make sure optimal, efficient, repeatable results free of cross-contamination. The KrosFlo Research II has a variety of alarms to alert users to changes in pressure and in the permeate as well as a high-pressure shut-off to protect membrane integrity.

The Spectrum Lab KrosFlo Research II TFF System is supported with powerful KF Comm software, which graphs run data for users automatically, with specifics like flow rates, as well as inlet, retentate, and transmembrane pressures into a spreadsheet for analysis. On the instrument itself, an easy to read, backlit, the digital display allows users to monitor recirculation flow rate and pressures in real-time. This TFF system comes equipped with Hollow Fiber filtration modules. The hollow fiber modules of this ultrafiltration system give you a gentle separation while avoiding membrane fouling, and recouping maximum product. By using a disposable flow path, users not only avoid cross-contamination worries but also avoid the hassle of re-validating modules before the next run, giving you faster turnarounds and results you can count on.

Specifications

Spectrum Lab KrosFlo Research II TFF System Specifications:

Output
Speed: 0.1 to 600 rpm
Torque output, Maximum: 180 oz-in (13 kg•cm) 540 oz-in Starting
Speed regulation: Line ±0.1% F.S. Load ±0.1% F.S. Drift ±0.1% F.S.
Pressure Sensor Limits: -5.0 to 45.0 psi
Input
Supply voltage limits: 90 to 260 Vrms @ 50/60 Hz
Current, max.: 2.2A @ 115 Vrms, or 1.1A @ 230 Vrms
General
Temperature, Operating: 0° to 40°C (32° to 104°F)
Temperature, Storage:  –25° to 65°C (–13° to 149°F)
Humidity (non-condensing): 10% to 90%
Dimensions 12 x 16 x 22”
Weight 28 lb (unit and parts)
Power 115/230 VAC, 50/60 Hz, 2.2/1.1A

Included

Included with Spectrum Lab KrosFlo Research II TFF System

  • KrosFlo Sectrum TFF System KR2i
  • Touch Screen Controller (Tablet Running Software)
  • KrosFlo Scales
  • KrosFlo Pumps
  • Stand for Controller
  • Communication Cable
  • User Manual
  • 120V Power Cord
  • 30-Day Warranty

Notes

Technical Notes

This Spectrum Lab KrosFlo Research II TFF System has been fully inspected and is performing to expectations. All of our lab equipment comes backed with our standard warranty. Should you have any questions, please don’t hesitate to contact us.

Video

Spectrum Lab KrosFlo Research II TFF System Video

KrosFlo TFF System ID 15428
