Description
Description
KrosFlo TFF System
The KrosFlo Research II Tangential Flow Filtration System provides fast, gentle microfiltration and ultrafiltration with maximized product recovery for small applications. This TFF system has a flow rate range from 0.01 to 2300 ml per minute and uses a disposable flow path and digital pressure monitor to make sure optimal, efficient, repeatable results free of cross-contamination. The KrosFlo Research II has a variety of alarms to alert users to changes in pressure and in the permeate as well as a high-pressure shut-off to protect membrane integrity.
The Spectrum Lab KrosFlo Research II TFF System is supported with powerful KF Comm software, which graphs run data for users automatically, with specifics like flow rates, as well as inlet, retentate, and transmembrane pressures into a spreadsheet for analysis. On the instrument itself, an easy to read, backlit, the digital display allows users to monitor recirculation flow rate and pressures in real-time. This TFF system comes equipped with Hollow Fiber filtration modules. The hollow fiber modules of this ultrafiltration system give you a gentle separation while avoiding membrane fouling, and recouping maximum product. By using a disposable flow path, users not only avoid cross-contamination worries but also avoid the hassle of re-validating modules before the next run, giving you faster turnarounds and results you can count on.
Specifications
Specifications
Spectrum Lab KrosFlo Research II TFF System Specifications:
Output | |
Speed: | 0.1 to 600 rpm |
Torque output, Maximum: | 180 oz-in (13 kg•cm) 540 oz-in Starting |
Speed regulation: | Line ±0.1% F.S. Load ±0.1% F.S. Drift ±0.1% F.S. |
Pressure Sensor Limits: | -5.0 to 45.0 psi |
Input | |
Supply voltage limits: | 90 to 260 Vrms @ 50/60 Hz |
Current, max.: | 2.2A @ 115 Vrms, or 1.1A @ 230 Vrms |
General | |
Temperature, Operating: | 0° to 40°C (32° to 104°F) |
Temperature, Storage: | –25° to 65°C (–13° to 149°F) |
Humidity (non-condensing): | 10% to 90% |
Dimensions | 12 x 16 x 22” |
Weight | 28 lb (unit and parts) |
Power | 115/230 VAC, 50/60 Hz, 2.2/1.1A |
Included
Included
Included with Spectrum Lab KrosFlo Research II TFF System
- KrosFlo Sectrum TFF System KR2i
- Touch Screen Controller (Tablet Running Software)
- KrosFlo Scales
- KrosFlo Pumps
- Stand for Controller
- Communication Cable
- User Manual
- 120V Power Cord
- 30-Day Warranty
Notes
Notes
Technical Notes
This Spectrum Lab KrosFlo Research II TFF System has been fully inspected and is performing to expectations. All of our lab equipment comes backed with our standard warranty. Should you have any questions, please don’t hesitate to contact us.
Video
Video
Spectrum Lab KrosFlo Research II TFF System Video
KrosFlo TFF System ID 15428
